PRODUCT DESCRIPTION The G10 product family is characterized by optimum detection performance wherever space is at a premium. It supports numerous different options for optics, electronics, principles of operation, power supplies, and switching outputs. Combined with an extensive range of accessories, these sensors are able to support a wide variety of applications. The patented Q-Lock assembly system for the G10 reduces the time required to install and align the sensor with an assembly rod to just a few seconds, making this the ideal product for logistics applications. Summary: The G10 product family provides quick and flexible sensor installation, ensures error-free operation, and keeps costs under control. BENEFITS > Long sensing ranges for maximum operating reserves > Efficient installation: The G10 and the Q-Lock assembly system save valuable hours when mounting and commissioning multiple sensors > A single sensor family for all industrial and commercial fields of application > Universal DC or AC/DC power supply for even greater application flexibility > Highly reliable and durable despite optical interference or mechanical loads > Wide range of accessories simplifies sensor integration: aids for assembly, connecting cables, and reflectors FEATURES > Long sensing ranges: 1,200 mm with background suppression; 15 m on PL80A reflector > PinPoint LED with bright and precise light spot > Small housing design > 10 … 30 VDC or 24 … 240 VAC/VDC power supply with PNP/NPN or relay output > Rugged sensor housing with metal-reinforced holes for assembly > Q-Lock assembly system for mounting the sensor within a few seconds TECHNICAL DATA OVERVIEW Dimensions (W x H x D) 20 mm x 50 mm x 39 mm 20 mm x 50 mm x 51.5 mm Sensing range max. Photoelectric proximity sensor 20 mm ... 2,000 mm 1) Photoelectric retro-reflective sensor 0.08 m ... 17 m 2) 0.08 m ... 12.5 m 3) 0.15 m ... 5 m 4) Through-beam photoelectric sensor 0 m ... 80 m Light source LED / PinPoint LED Type of light Infrared light / visible red light Enclosure rating IP67 Housing material Plastic
